China 2/4/8 Way 18000-40000MHz wilkinson Power Divider or Power Splitter or power combiner Manufacture and Factory

2/4/8 Way 18000-40000MHz wilkinson Power Divider or Power Splitter or power combiner

Short Description:

• Model Number: KPD-18/40-2S,4S,8S

• These Power Splitter with compact size for flexibility in installation

• 18000-40000MHz Power Splitter Divides 2/4/8 Way input power equally

• 2/4/8 Way Power dividers can be used as combiners or splitters

•Custom and optimized designs are available

keenlion can provide customize Power Divider, free samples, MOQ≥1

Any inquiries we are happy to reply, pls send your questions and orders.

Send email to us

Product Detail

Product Tags

Keenlion stands out as a dependable factory for high-quality 2/4/8 Way 18000～40000MHz Power Dividers. The 2/4/8 Way Power Dividers are designed to efficiently split and distribute rf signals within a frequency range of 18000 to 40000MHz.Power Divider isolation≥18dB, High isolation between output ports to prevent interference.

Main Indicators KPD-18/40-2S

Product Name	Power Dvider
Frequency Range	18000～40000 MHz
Insertion Loss	≤1.0dB(Does not include Theoretical Loss 3dB)
Amplitude balance：	≤±0.4dB
Phase balance:	≤±5°
VSWR	≤1.5: 1
Isolation	≥18dB
Impedance	50 OHMS
Connectors	2.92-Female
Power Handling	Splitter 20W/Combiner 1W
Surface Color	Paint Black
Weight	20g
Operation Temperature	-40℃ ~ +70℃
Size Tolerance	As Below ↓（±0.5mm）

Main Indicators KPD-18/40-4S

Product Name	Power Dvider
Frequency Range	18000～40000 MHz
Insertion Loss	≤1.5dB(Does not include Theoretical Loss 6dB)
Amplitude balance：	≤±0.4dB
Phase balance:	≤±5°
VSWR	≤1.5: 1
Isolation	≥16dB
Impedance	50 OHMS
Connectors	2.92-Female
Power Handling	Splitter 20W/Combiner 1W
Surface Color	Paint Black
Weight	70g
Operation Temperature	-40℃ ~ +70℃
Size Tolerance	As Below ↓（±0.5mm）

Outline Drawing

Main Indicators KPD-18/40-8S

Product Name	Power Dvider
Frequency Range	18000～40000 MHz
Insertion Loss	≤2.5dB(Does not include Theoretical Loss 9dB)
Amplitude balance：	≤±0.6dB
Phase balance:	≤±6°
VSWR	≤1.7: 1
Isolation	≥15dB
Impedance	50 OHMS
Connectors	2.92-Female
Power Handling	Splitter 20W/Combiner 1W
Surface Color	Paint Black
Weight	140g
Operation Temperature	-40℃ ~ +70℃
Size Tolerance	As Below ↓（±0.5mm）

Outline Drawing

advantages

In the dynamic communication industry, Keenlion, a seasoned production - based factory, proudly presents its high - performance 18000 - 40000MHz Power Divider.
Exceptional Performance
Keenlion's 18000 - 40000MHz Power Divider is engineered with precision. It offers low insertion loss, ensuring minimal power dissipation during signal division. This results in efficient power distribution across multiple paths. The device also has excellent amplitude and phase balance, guaranteeing consistent signal quality among output ports. For instance, in millimeter - wave communication systems operating within this frequency range, it enables seamless signal splitting for better coverage and data transfer.
Diverse Applications
This power divider finds extensive use in various communication setups. In 5G and emerging 6G networks, it is crucial for distributing power to multiple antennas, enhancing network capacity and performance. In satellite communication ground stations, it helps in dividing the received power for different processing units.

Conclusion

With over 20 years of experience, Keenlion provides customization for the 18000 - 40000MHz Power Divider. We offer samples for clients to evaluate the product. Our competitive pricing, fast delivery, and end - to - end support make us the ideal choice for your communication needs. Trust Keenlion for top - notch 18000 - 40000MHz Power Divider
