Best Hybrid Coupler Combiner Factories – RF 824-960MHz/1710-1880MHz/1920-2170MHz Triplexer 3 Way Passive Combiner – Keenlion

Short Description:

Product Detail

Product Tags

Feedback (2)

With our superb management, potent technical capability and strict quality command procedure, we go on to provide our shoppers with trustworthy high-quality, reasonable costs and outstanding services. We goal at becoming considered one of your most trustworthy partners and earning your pleasure for Rf Passive Component, Coupling Plate, Custom Cavity Filter, With the eternal goal of "continuous quality improvement, customer satisfaction", we are sure that our product quality is stable and reliable and our products are best-selling at home and abroad.

Best Hybrid Coupler Combiner Factories – RF 824-960MHz/1710-1880MHz/1920-2170MHz Triplexer 3 Way Passive Combiner – Keenlion Detail:

Product Overview

The 824-960MHz/1710-1880MHz/1920-2170MHz 3 Way Combiner is a universal microwave/millimeter wave component,the Combiners are generally used at the transmitting end, whose function is to combine two or more radio frequency signals from different transmitters into one radio frequency device sent to antenna for transmission, and at the same time avoid mutual influence between signals of various ports. The combiner generally has two or more input ports and only one output port. Port isolation is an important indicator, which is used to describe the ability of two signals to not affect each other.

Typical applications

It has a good function of frequency selection and filtering in circuits and electronic high-frequency systems, and can suppress useless signals and noise outside the frequency band

It is used in aviation, aerospace, radar, communication, electronic countermeasure, radio and television and various electronic test equipment

When using, pay attention to the good grounding of the shell, otherwise it will affect the out of band suppression and flatness index

Main Indicators

Number	Specifications	GSM	DCS	WCDMA
1	Frequency Range	824～960 MHz	1710~1880 MHz	1920～2170 MHz
2	Insertion Loss	≤0.5dB	≤0.8dB	≤0.85dB
3	Ripple in Band	≤0.4dB	≤0.6dB	≤0.7dB
4	VSWR	≤1.3	≤1.3	≤1.4
5	Rejection	≥80dB@1710~2170 MHz	≥75dB@1920~2170 MHz	≥75dB@824~1880 MHz
5	Rejection	≥80dB@1710~2170 MHz	≥80dB@824~960 MHz	≥75dB@824~1880 MHz
6	Power Handling	100W
7	PIM3	≤-120dBc（2×43dBm）
8	Port Connectors	N-Female（50Ω）
9	Surface Finish	black paint
10	Port Sign	Public Port:COM; Port 1: GSM; Port 2: DCS; Port 3: WCDMA
11	Configuration	As Below

Outline Drawing

cghf (2)

Packaging & Delivery

Selling Units:Single item

Single package size: 17X9.2X5.2 cm

Single gross weight:1.5.000 kg

Package Type:Export Carton Package

Lead Time：

Quantity(Pieces)	1 - 1	2 - 500	>500
Est. Time(days)	15	40	To be negotiated

Company Profile

Sichuan Keenlion Microwave Technology Co., Ltd. is a professional manufacturer of microwave passive components in the industry. The company is committed to providing customers with high-performance products and high-quality services to create long-term value growth for customers.

Sichuan clay Technology Co., Ltd. focuses on the independent R & D and production of high-performance filters, multiplexers, filters, multiplexers, power division, couplers and other products, which are widely used in cluster communication, mobile communication, indoor coverage, electronic countermeasures, aerospace military equipment systems and other fields. Facing the rapidly changing pattern of the communication industry, we will abide by the constant commitment of “creating value for customers”, and are confident to continue to grow with our customers with high-performance products and overall optimization schemes close to customers.

1.Company Name:Sichuan Keenlion Microwave Technology

2. Date of establishment:Sichuan Keenlion Microwave Technology Founded in 2004.Located in Chengdu, Sichuan Province, China.

3. Process flow:Our company has complete production line (Design – cavity production – assembly – commissioning – testing – delivery), which can complete the products and deliver them to customers at the first time.

cghf (1)

4.Freight mode:Our company has cooperation with major domestic express companies and can provide corresponding Express Services according to customer requirements.

FAQ

Q:RF 16 channel 1mhz-30mhz core power distributor with SMA connector can be modified?

A:Yes, our company can provide customized services according to customer requirements, such as size, appearance color, coating method, joint model, etc.

Q:Can the epidemic situation be serious enough to deliver goods abroad? Will the epidemic situation affect the delivery progress abroad?

A:It can be shipped abroad, but the receiving time may be extended in areas with serious epidemic.
