Customized RF Cavity Filter 1405MHz Band Pass Filter

Customized RF Cavity Filter 1405MHz Band Pass Filter

Short Description:

The Big Deal

• Very low insertion loss with excellent power handling

• Very fast roll-off with wide stopband

• Passbands up to 150MHZ

• Stopbands up to 20 GHz

Product Detail

Product Tags


Product Overview

1.A band-pass Cavity filter is a device that allows a particular frequency band to block other frequencies simultaneously.

2.Center Frequency:1405MHz,Insertion Loss:≤1.0dB,VSWR≤1.3,Port Connectors:SMA-Female

3 The filter has the characteristics of low insertion loss, high resistance band rejection

4.With high reliability, stable and reliable working performance 100% brand new and high quality

5. Applications :Test and measurements, Lab use

6. Model Number:04KBF-1405/150M-01S

7.The RF Cavity Filter is a universal microwave/millimeter wave component, which is a kind of device that allows a particular frequency band to block other frequencies simultaneously. RF and Microwave Filters are used to filter out unwanted signals from entering a system. With the increase of wireless standards in the existing frequency bands, filters now play an extremely important role and are required to minimize interference. They are designed to operate at specific frequencies and allow/attenuator RF signals at different frequencies. RF Filters have two types of frequency bands - passband and stopband. Signals which lie in the passband can pass through with minimal attenuation while signals which lie in the stopband experience heavy attenuation.Filter Type: There are a number of different types of RF filters - Band Pass Filters, Low Pass Filters, Band Stop Filters, High Pass filters etc. Each type operates in a different way.Technology: Based on the required application and size of the wireless system there are a number of filter types - Notch Filters, SAW Filters, Cavity Filters, Waveguide Filters etc. Each one has different properties and different form factors.Passband Frequency (MHz): This is the frequency range where signals can pass through with minimal attenuation.Stopband Frequency (MHz): This is the frequency range where the signals are attenuated. The higher the attenuation the better. This is also called isolation.Insertion Loss (dB): It is the loss that occurs while a signal is traveling through the passband frequency range. The lower the insertion loss the better the filter performance.Stopband Attenuation (dB): It is the attenuation experienced by signals which lie in the stopband of a given filter. The magnitude of attenuation faced by signals can vary according to their frequency.

Key Features



Low insertion loss

Low signal loss results in better SNR in receiver front end and better power delivery to antenna in transmitter

Fast roll-off

Higher selectivity results in better adjacent channel rejection and dynamic range

Wide stopband

Wide spur free band results in better receiver sensitivity

High power handling

Well suited for transmitter application

Protective assembly

Prevents accidental de-tuning of precisely tuned resonant circuit

Main indicators

Center Frequency 1405MHz
Bandwidth 150MHz
Insertion Loss ≤1.0dB
VSWR ≤1.3
Rejection ≥35dB@1310MHz , 1500MHz ≥40dB@1290MHz ,1520MHz ≥55dB@1250MHz ,1560MHz

≥75dB@1230MHz ,1580MHz

Port Connector SMA-Female
Surface Finish Painted black
Dimension Tolerance ±0.5mm
Center Frequency 1405MHz
Bandwidth 150MHz
Insertion Loss ≤1.0dB

Outline Drawing


Packaging & Delivery

Selling Units:Single item

Single package size:20X10X8 cm

Single gross weight:1kg

Package Type:Export Carton Package

Lead Time:

Quantity(Pieces) 1 - 1 2 - 500 >500
Est. Time(days) 15 40 To be negotiated
